| Product description |
PET Preform Injection Molding Machine is mainly used for the molding of reinforced PET. This machine can produce plastic coat hangers, dustpans, brooms, trays, etc. It is versatile, used with high precision, good quality and short production cycle. The screws are generally hardened to effectively avoid abrasion after long-term use. Our machines are excellent for making and processing PET products, and they are of reliable quality.
Our PET Preform Injection Molding Machine our machine is driven by servo hydraulic system, which has the advantages of low noise, high efficiency and energy saving. It adopts high efficiency plasticizing screw with hair length-diameter ratio, and the plasticizing efficiency far exceeds the industry average. Its central clamping structure can save more raw materials for the mold. In addition, our machine is equipped with an enlarged plasticizing motor for faster preforming and increased ejection force, thus greatly improving productivity.
Here we recommend an injection molding machine for the production of plastic daily use products. Plastic daily necessities play an irreplaceable role in our daily life because they are lightweight, durable and cost-effective, and they are also a necessity of life. Therefore, there is a huge market for our machines at all times.
| Main Parameters |
| Screw diameter | mm | 35 | 40 | 45 |
| Screw L/D ratio | L/D | 24.5 | 21 | 18.7 |
| Shot weight | gram | 158 | 206 | 260 |
| Injection capacity | cm3 | 173 | 226 | 286 |
| Injection pressure | Mpa | 235 | 180 | 142 |
| Theoretical injection rate | g/s | 110 | 143 | 181 |
| Plastic capacity | g/s | 13.8 | 19.7 | 27.1 |
| Injection stoke | mm | 180 | ||
| Screw torque | N.m | 740 | ||
| Max screw rotate speed | r/min | 250 | ||
| Clamping force | Ton | 130 | ||
| Opening stroke | mm | 400 | ||
| Space between tie bars | mm | 420x420 | ||
| Mould height | mm | 160~440 | ||
| Max daylight | mm | 840 | ||
| Ejector force | ton | 3.14 | ||
| Ejector stroke | mm | 100 | ||
| Ejector quantity | 5 | |||
| Oil pump motor | kw | 15 | ||
| Pump pressure | Mpa | 10 | ||
| Heating power | kw | 9.2 | ||
| Machine size | M | 4.7*125*1.85 | ||
| Machine weight | ton | 4.3 | ||
| Oil tank capacity | L | 360 | ||
| International designation | 1300-410 | |||
| Detail image |
| The main parts |
| Company information |
| Our services & after-sale guarantee |
One-year warranty for core components and lifetime maintenance
One-stop service
Deep Processing
Lots of free accessories
Free professional guidance
| Certification |
| Service Buyer |
Our aim is to solve problems for customers and satisfy them. Therefore, we attach great importance to the user experience of our products and the after-sales service. I hope our sincerity can push us to further each other's business.
